IBIS Images - flow diagrams

To download, right click on image and select "Save Image As"

Number of pages per sheet

4 Page Sheets

Plow folded, portrait format

Plow folded, landscape format

Plow folded, no cover, portrait format

90 degree direction change (eg from cut-sheet printer), plow folded, no cover, portrait format

4-page sheets (center-split in webcutter) feed 2-up from web-cutter. Handler revolves them manually and enter Smart-binder long-edge leading. Plow-folded. Portrait format

Folded one third/two thirds page width

Fed from Sheet Pile Feeder SB-095 or SB-097 (off-line), portrait format

Fed from three sheet pile feeders, SB-095, SB-096, SB-096 (off-line), portrait format

Fed from SB-096 sheet pile feeder. Plow folded, portrait format

Rotation, then 90 degree direction change, plow-folding, portrait format

Rotation, then showing passing straight through TUSDC-100 sheet seperator, then 90 degree direction change, plow-folding, portrait format

8 Page Sheets

Buckle folded with F-100 then plow folded, portrait format

Buckle folded with F-100 & plow folded, landscape format

Signature production, buckle folded and plow folded - no trimming, portrait format

Rotation and folding with the SRF-100, then plow folded, portrait format

Folded, then through web-cutter, then 90 degree direction change, & plow folded, portrait format

2-up, portrait format

2-up 90 degree direction change, portrait format

2-up 90 degree direction change, plow-folded, landscape format

2-up, 8 page sheets, plow-folded, landscape format

2-up, 8 page sheets, fed offline from Sheet pile feeder (SB-095 or SB-097), plow folded, landscape format

TUSDC-100 2-up sheet direction change system (ie 8 pages per sheet before center slitting prior to TUSDC-100), portrait format

Plow folded then 2nd plow fold, portrait format

Web perforated in web-cutter along middle, glue dots applied along middle of one side, and also down center, web cut-off creating 8 page sheets, then plow-folded, portrait format

16 Page Sheets

2-up (with center knife), with rotation (SR-100), portrait format

24 Page Sheets

6-up production, using the Bickel SGU trimmer (24-page sheets) landscape format
